Output
Max Configurable Power (Watts)
800 Watts / 1.0kVA
Output Voltage Note
Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load
88.0 %
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages
220, 240
Load Crest Factor
3 : 1
Topology
Double conversion online
Waveform type
Sine wave
Input
Input frequency
40 – 70 Hz
Input voltage range for main operations
160 – 280V
Number of Power Cords
1
Efficiency at Full Load
88.0 %
Other Input Voltages
220, 240
Batteries & Runtime
Battery type
Lead-acid battery
Typical recharge time
4hour(s)
Battery Charge Power (Watts)
129 Watts
Extendable Run Time
1
Battery Volt-Amp-Hour Capacity
324
Extended Run Options
Runtime
Efficiency
Communications & Management
Control panel
Multifunction LCD status and control console
Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating
600Joules
Physical
Maximum Height
172MM, 17.2CM
Maximum Width
438MM, 43.8CM
Maximum Depth
412MM, 41.2CM
Net Weight
27.0KG
Shipping weight
33.5KG
Shipping Height
480MM, 48.0CM
Shipping Width
500MM, 50.0CM
Shipping Depth
600MM, 60.0CM
Environmental
Operating Temperature
0 – 40 °C
Operating Relative Humidity
0 – 95 (Non-condensing) %
Operating Elevation
0 – 3048meters
Storage Temperature
-20 – 50 °C
Storage Elevation
0 – 14999.8meters
Protection Class
IP20
Conformance
Approvals
CE, IEC 62040-1-1, IEC 62040-1-2
Standard warranty
2 years repair or replace
