GPU SuperServer SYS-220GP-TNR (Complete System Only)

Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors
Intel® C621A Chipset
16 DIMM Slots; Up to 4TB DRAM; Up to 4TB Intel® Optane™ Persistent Memory (up to 6TB with DRAM) ; 3200/2933/2666 ECC DDR4 LRDIMM;RDIMM; Intel® Optane™ Persistent Memory 200 series
- 6 PCIe Gen 4.0 x16 FH, 10.5″ L
- Up to 2 PCIe Gen 4.0 x8 FH
Flexible networking options
- Total 10x 2.5″ Hot-swap drive bays, configurable combination of SATA + NVMe with optional cable, up to 6x NVMe
- Configuration 3: 4x SATA + 6x NVMe
- 2x M.2 NVMe for boot drive only (with optional expansion card AOC-SLG3-2M2)
- Configuration 1: 8x SATA + 2x NVMe (PCIe slot 7 + slot 8 enabled)
- Configuration 2: 6x SATA + 4x NVMe (PCIe slot 7 enabled)
5 counter rotating fans w/ Optimal Fan Speed Control
2x 2600W redundant Titanium level power supplies

Product SKUs
SuperServer SYS-220GP-TNR

Motherboard
Super X12DPG-AR

Processor
CPU	Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors
Core Count	Up to 40C/80T; Up to 60MB Cache per CPU
Note	Supports up to 270W TDP CPUs (Air Cooled)

GPU
Max GPU Count	Up to 6 double-width or 8 single-width GPU(s)
Supported GPU	NVIDIA PCIe: A40, RTX A6000, RTX A5000, RTX A4500, RTX A4000, A40, A30, A16, A2, A100, A10 View GPU Options
CPU-GPU Interconnect	PCIe 4.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect	PCIe
Certification

System Memory
Memory	Slot Count: 16 DIMM slots Max Memory (2DPC): Up to 4TB 3200MT/s ECC DDR4 RDIMM/LRDIMM Supports Intel® Optane™ persistent memory 200 series View Memory Options
Memory Voltage	1.2V

On-Board Devices
SATA	SATA (6Gbps) ; RAID 0/1/5/10 support
Chipset	Intel® C621A
Network Connectivity	Via AIOM View AIOM Options View AOC Options

Input / Output
Video	1 VGA port(s)

System BIOS
BIOS Type	AMI 32MB SPI Flash EEPROM

Management
Software	SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New!
Power configurations	Power-on mode for AC power recovery ACPI Power Management

Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery System Lockdown

PC Health Monitoring
CPU	Monitors for CPU Cores, Chipset Voltages, Memory 7 +1 Phase-switching voltage regulator
FAN	Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors

Dimensions and Weight
Height	3.46″ (88 mm)
Width	17.35″ (440.7 mm)
Depth	30.18″ (766.8 mm)
Package	11″ (H) x 26.5″ (W) x 44.5″ (D)
Weight	Gross Weight: 54 lbs (24.5 kg) Net Weight: 39.5 lbs (17.9 kg)
Available Color	Black Front & Silver Body

Front Panel
LED	Hard drive activity LED Information LED Network activity LEDs Power status LED UID LED

Expansion Slots
PCI-Express (PCIe) Configuration	Default 6 PCIe 4.0 x16 FH/10.5″L slot(s) 2 PCIe 4.0 x8 FHFL slot(s) View AOC Options

Drive Bays / Storage
Drive Bays Configuration	Default: Total 10 bay(s) 6 front hot-swap 2.5″ SAS/SATA drive bay(s) 4 front hot-swap 2.5″ NVMe drive bay(s) (SAS support may require additional storage controller and/or cables, please see the optional parts list for details) View Drive Options
M.2	View M.2 Options

System Cooling
Fans	5 heavy duty fans with optimal fan speed control

Power Supply

1x 2600W Redundant Titanium Level (96%) power supply

Operating Environment
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
